DS-2TD2636B-13/P

Temperature Screening Thermographic Bullet Camera

Key Feature

384 × 288 high resolution in thermal channel, high sensitivity sensor
Temperature range: 30°C to 45°C; temperature accuracy: ±0.5 °C
Reliable temperature exception alarm function
4MP resolution in optical channel
3D DNR, image detail enhancement

Specification

Thermal Module

Image sensor

Vanadium Oxide Uncooled Focal Plane Arrays

Max. Resolution

384 × 288

Pixel Pitch

17μm

Response waveband

8μm to 14μm

NETD

< 40mK (@ 25 °C,F#=1.0)

Lens (Focal Length)

13 mm

IFOV

1.3mrad

Field of View

28,8° × 21.6° (H × V)

Min. Focus Length

2 m

Aperture

F 1.0

Optical Module

Max. Image Resolution

2688 × 1520

Image Sensor

1/2.7" Progressive Scan CMOS

Min. Illumination

Color: 0.0089 Lux @(F1.6, AGC ON), B/W: 0.0018 Lux @(F1.6, AGC ON)

Shutter Speed

1 s to 1/100,000 s

Lens (Focal Length)

6 mm

Field of View

51.7° × 28° (H × V)

WDR

120 dB

Day & Night

IR cut filter with auto switch

Image Function

Bi-spectrum Image Fusion

Display the details of optical channel on thermal channel

Picture in Picture

Display partial image of thermal channel on the full screen of optical channel

Smart Function

Temperature Measurement

3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)

Thermographic Range

30 °C to 45 °C

Thermographic Accuracy

± 0.5 °C

Infrared

IR Distance

Up to 50 m

IR Intensity and Angle

Automatically adjusted

Network

Main Stream

Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240)

Sub-stream

Optical: 50 Hz: 25 fps (704 × 576, 352 × 288, 176 × 144) 60 Hz: 30 fps (704 × 480, 352 × 240, 176 × 120) Thermal: 25 fps (704 × 576, 352 × 288, 320 × 240)

Video Compression

H.265/H.264/MJPEG

Audio Compression

G.711u/G.711a/G.722.1/MP2L2/G.726/PCM

Protocols

IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE

Simultaneous Live View

Up to 20

User/Host Level

Up to 32 users, 3 levels: Administrator, Operator, User

Security Measures

User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering

Integration

Alarm Input

2-ch inputs (0-5 VDC)

Alarm Output

2-ch relay outputs, alarm response actions configurable

Alarm Action

SD recording/relay output/smart capture/FTP upload/email linkage

Audio Input

1, 3.5 mm Mic in/Line in interface. Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%

Audio Output

Linear level, impedance: 600 Ω

Reset

1, Reset Button

Communication Interface

1, RJ45 10M/100M self-adaptive Ethernet interface. 1, RS-485 interface

SD Memory Card

Built-in micro SD card slot, support Micro SD/SDHC/SDXC card (up to 256 GB) Supports manual/alarm recording

Application Programming

Open-ended API, support ISAPI, HIKVISION SDK and third-party management platform, ONVIF (Profile S, Profile G, Profile T)

Client

iVMS-4200, Hik-Connect

Web Browser

IE 8-11, Chrome 41-44, Firefox 30-51

General

Menu language

32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)

Power

24 VAC± 25%, 12 VDC± 25%, two-core terminal block PoE (802.3af, class 3)

Power Consumption

18 VAC to 30 VAC: 0.38 A to 0.22 A, max. 9 W 9 VDC to 15 VDC: 0.63 A to 1.06 A, max. 9 W PoE (802.3af, class 3): 44 V to 57 V, 0.22 A to 0.17 A, max. 9.5 W

Working Temperature/Humidity

Temperature: 10 °C to 35 °C（Indoor and windless environment use only） Humidity: 95% or less

Protection Level

IP66 Standard TVS 6000V lightning protection, surge protection, voltage transient protection

Dimensions

376.1 mm × 119.1 mm × 118.1 mm (14.81" × 4.68" × 4.65")

Weight

Approx. 1.82 kg (4.01 lb)

*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
